Manual Shrinking Tool

HUMBOLDT - RIPACK 2500


Hand shrink device type: HUMBOLDT - Ripack 2500.
Lightest device in its class for fatigue-free work with double
security, automatic shutdown and robust housing.

HUMBOLDT - RIPACK 2500
  • Patented system “cold burner head" protects against burns
  • Ergonomic handle
  • Adjustable power between 34 and 60 kW
  • Max. Gas consumption in continuous operation: approx. 4 kg / h
  • CO / CO2 emissions only 0.037
  • Swiveling burner head off stainless steel for working in vertical and horizontal position
  • Inlet thread: 3/8 left
  • Propane operation
  • Adjustable working pressure from 1.5 - 3.5 bar

Product-Specification
Weight:
973 g
Length:
365 mm
Nominal heat load:34 - 60 kW
Sound level:<85 dbA
Hose length:
8 m
Pressure reducer:
With double locking
Work pressure:
1.5 - 3.5 bar
Specification
Gas:
Propane gas, optional natural gas possible
Assembly instructions:
German
Equipment:
Replacement igniter and
torsional connector
Optional:

HUMBOLDT - RIPACK Tasche
Bag with accessories

HUMBOLDT - Haubenfertiger
Hood paver

HUMBOLDT - RIPACK 3000


Hand shrink device type: HUMBOLDT - Ripack 3000.
One of the most powerful shrink guns with high security and robust housing.

HUMBOLDT - RIPACK 3000
  • Patented system “cold burner head" protects against burns
  • Ergonomic handle with swivel joint, self-alignment of the burner hose
  • Adjustable power between 45 and 76 kW
  • Max. Gas consumption in continuous operation: approx. 4 kg / h
  • CO / CO2 emissions only 0.037
  • Swiveling burner head off stainless steel for working in vertical and horizontal position
  • Inlet thread: 3/8 left
  • Propane operation
  • Adjustable working pressure from 1.5 - 3.5 bar

Product-Specification
Weight:
1,220 g
Length:
375 mm
Nominal heat load:45 - 76 kW
Sound level:<85 dbA
Hose length:
8 m
Pressure reducer:
With double locking
Work pressure:
1.5 - 3.5 bar
Specification
Gas:
Propane gas, optional natural gas possible
Assembly instructions:
German
Equipment:
Replacement igniter and
torsional connector
Optional:

HUMBOLDT - RIPACK Tasche
Bag with accessories

HUMBOLDT - Haubenfertiger
Hood paver
